5KVA Must Inverter & 5.1kw Svolt Rack Mount Lithium battery ***Black Nov Deal***

5kVA MUST Inverter

Note:

1) Fan comes on during charging, load shedding and periodically during normal operation

2) If installing in a DB board, please make sure to add a separate Earth & Neutral to the inverter output circuit to mitigate chances of surges

Please note that to use these unit is parallel you will need the parallel kit additionally:

Features

– Pure sine wave output
– Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
– Built-in MPPT solar charge controller
– MAX PV Array Open Circuit Voltage: 450V
– Can provide the power to the load without battery
– Combining solar system, AC utility, and battery power source to supply continuous power
– Overload, short circuit and Deep discharge protection
– Cold start function
– Support USB, RS485 monitoring function

Specifications

-Nominal Battery System Voltage: 48VDC

Inverter Output

– Rated Power: 5200VA / 5200W
– Surge Power: 10400W
– Waveform: Pure sine wave
– AC Voltage Regulation (Batt.Mode): 230VAC±5%(Setting)
– Inverter Efficiency(Peak): 93%
– Transfer Time: 10ms (UPS / VDE4105) / 20ms (APL)

AC Input

– Voltage: 230VAC±5%
– Selectable Voltage Range: 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
– Frequency Range: 50Hz / 60Hz(Auto sensing)

Battery

– Normal voltage: 48VDC
– Floating Charge Voltage: 54.8VDC
– Overcharge Protection: 60VDC

Solar charger & AC Charger

– Maximum PV Array Open Circuit Voltage: 450VDC
– Maximum PV current: 18A
– PV Array MPPT Voltage Range: 150~430 VDC
– Maximum Solar Charge Current: 80Amp
– Maximum AC Charge Current: 60Amp
– Maximum Charge Current: 80Amp

Mechanical Specifications

– Machine Dimensions (W*H*D)(mm): 295*528*121
– Package Dimensions (W*H*D)(mm): 628*425*251
– Net Weight(kg): 14
– Gross Weight(kg): 15

Other

– Humidity: 5% to 95% Relative humidity (Non-condensing)
– Operating Temperature: 0°C~50°C
– Storage Temperature: -15℃ ~60℃

5.1kwh SVolt Lithium Battery

The tomu SVOLT 51.2V 106Ah A-Grade Lithium Battery is manufactured by a world-leading manufacturer SVOLT using A-Grade Battery cells. This allows superior performance, capacity, and reliability. Using state of high power A-Grade cell technology, the Lithium Battery is designed for environmentally sensitive areas and is committed to recycling.

The tomu SVOLT 51.2V 106Ah A-Grade Lithium Battery is widely used in industrial, residential, commercial, and private applications. The maintenance-free construction and advanced design features make the Lithium Battery the definitive choice for a wide variety of markets – Like solar and renewable energy storage for electric vehicles, industrial equipment, medical equipment, telecommunications, TVs, and UPS systems.

Features:
– A-Grade Cell Technology
– Maintenance-free
– Environmentally Friendly
– Wide Variety of Markets
– Renewable Energy
– 7 Protection Features
– Built-in Battery Management System
– Mountable
– 5-year Warranty

Battery Specifications:
– Battery Type-Chemistry: LiFePO4
– Nominal Voltage: 51.2V
– Nominal Capacity: 106Ah
– Energy Density: 5427.2Wh
– Terminal Type: M6
– Terminal Torque: 8.5NM
– Case Material: Metal
– BMS Built-in: Yes
– Internal Resistance: – Efficiency – Round Trip: >99.5%
– Self Discharge per Month: – Max Parallel Connectors: 16Pcs
– Series Connections: Not Allowed
– Cycle Life(0.2C, 25 C @ 80% DOD): >4000 Cycles
– Discharge Temperature: -20 C to 65 C
– Charge Temperature: 0 C to 45 C
– Storage Temperature: -10 C to 30 C
– Voltage Window: 44.8 – 57.6V
– Recommended Charge Voltage: 57.6 0.20V
– Max Charge Voltage: 58.4 0.20V
– Recommended Charge Current: 50A
– Max Continuous Charge Current: 100A
– Recommended Discharge Voltage: 44.8 0.20V
– Max Discharging Voltage: 43.2 0.20V
– Max Continuous Discharge Current: 100A
– Peak Discharge Current: 120A (5s 2s)
– Dimensions: L 566 x W 402 x H135 mm
– Weight: 47Kg

BMS Characteristics:
– Primary Charging Protection: (Current: 80A) (Delay Time:1000ms)
– Secondary Charging Protection: (Current: 100A) (Delay Time:500ms)
– Primary Discharging Protection: (Current: 110A) (Delay Time: 5s 2s)
– Secondary Discharging Protection: (Current: 120A) (Delay Time: 5s 2s)
– Over Charge Voltage Protection: (Voltage: 58.4V) (Delay Time:500ms)
– Over Discharge Voltage Protection: (Voltage: 43.2V) (Delay Time:500ms)
– Temperature Protection: (Temperature: 95 C) (Recover: 85 C)
– Communication Port: Major RS485,CAN/Dryport

What’s in the box
1 x SVOLT 51.2V 106Ah A-Grade Lithium Battery
1 x Red (Positive) Battery Cable
1 x Black (Negative) Battery Cable
1 x Ethernet cable
1 x Manual
