The SVOLT 51.2V 106Ah A-Grade Lithium Battery is manufactured by a world-leading manufacturer SVOLT which is joined with the Haval groups which we all know are extremely recognized for their vehicles, using A-Grade Battery cells. This allows superior performance, capacity, and reliability. Using state of high power, A-Grade cell technology, the Lithium Battery is designed for environmentally sensitive areas and is committed to recycling.
The SVOLT 51.2V 106Ah A-Grade Lithium Battery is widely used in industrial, residential, commercial, and private applications. The maintenance-free construction and advanced design features make the Lithium Battery the definitive choice for a wide variety of markets – Like solar and renewable energy storage for electric vehicles, industrial equipment, medical equipment, telecommunications, TVs, and UPS systems.
Specifications
- Energy:5.37kWh
- Installation Type: Rack Mounted
- Battery type-Chemistry: LiFePO4
- Nominal Voltage:51.2V
- Nominal Capacity :106Ah
- Energy Density:5427 2Wh
- Dimensions(LxWxH) :566’362’135mm
- Weight (Approx.):44KGS
- Terminal Type: M6
- Terminal Torque:8.5NM
- Case Material: SPCC
- BMS build-in: Yes
- Internal Resistance:<30mO
- Efficiency – round trip:99%
- Self Discharge per Month:<3%
- Max parallel connectors:16Pcs
- Series connections:Not Allowed
- Cycle life (0.2C, 25°C@80% DOD) Discharge Temperature:6000 Cycles
- Charge Temperature :20° C to 65°
- Storage Temperature :0C to 50° C
- Bluetooth(App) :Optional
- LCD Screen: Optional
- Heating Function: Optional
- Voltage Window: Optional
- Recommend Charge Voltage:43.2V-58.4V
- Max Charge Voltage:57.6±0.20V
- Recommend Charge current:58.4±0.20V
- Max Discharging Voltage:43.2±0.20V
- Max Continuous Discharge Current :100A
- Peak Discharge Current:150A
What’s In the Box:
- 1 x SVOLT 51.2V 106Ah A-Grade Lithium Battery
- 1 x Red (Positive) Battery Cable
- 1 x Black (Negative) Battery Cable
- 1 x Ethernet cable
- 1 x Manual
5 Years Warranty
10 Years Service Warranty
