DESCRIPTION
- SUNSYNK 5kW Inverter & Battery Combo Deal – 1 X SUNSYNK 5kW Inverter & 1 X 5kW 100Ah 51.2V Lithium-Ion Batteries
- Whats Included:
- 1 X SUNSYNK 5kW Hybrid Parity Inverter (1 Phase) – SUNSYNK-5K-SG02LP1
- 1 x SUNSYNK 5kW 100Ah LiFePo4 Lithium Ion Battery – SUN-BATT-5.32
More Details:
- SUNSYNK 5kW Hybrid Parity Inverter (1 Phase)
- Model SUNSYNK-5K-SG02LP1
- The Synsynk Hybrid Parity Inverter is a Highly Efficient Power Management Tool.
- Manages Power Flow from multiple sources such as Solar, Main Electrical Grids & Generator, then effectively storing & releasing electric power as the utilities require.
- Easy & Simple to Understand Display.
- Wi-Fi & GSM monitoring supported.
- Equipped with Visual power flow screen.
- Built-In 2 strings of MPP trackers.
- Smart settable 3-stage MPPT charging – optimized battery performance.
- Auxiliary load function.
- Parallel/multi-invert function grid-tied & off-grid.
- 220V Single Phase, Pure Sinewave Inverter.
- Grid Type: Split Phase, 2/3 Phase, Single Phase
- Protection Degree: IP65
- Noise Level: <30dB
- Maximum Charge & Discharge Current: 120A
- Battery Charging Strategy: Self-Adaptation to BMS
- Maximum DC Input Power: 6500W
- MPPT Range: 125-425V
- Start-up Voltage: 150V
- AC Output & UPS Power: 5000W
- Maximum AC Power: 5500W
- AC Output Rated Current: 20.8A
- Maximum AC Output Current: 24A
- Maximum Efficiency: 97.60%
- MPPT Efficiency: 96.50%
- Battery Type: Lead-acid or Lithium-ion (Not Included – Sold Separately)
- Battery Voltage Range: 40-60V
- Communication with BMS: CAN/RS485
- Fan Cooling
- Operation Temperature: -25°C to 60°C
- Installation Type: Wall Mounted.
- Maximum Altitude: 4000m
- Weight: 32Kg
- Dimensions (L x W x H): 670 x 420 x 233 mm
- 5 Year Limited Product Warranty. T & C’s Apply
- Recommended Solar Panel Configuration:
- Min 3 Panels – Max 14 Panels (Panel Size: 180W to 480W Panels) (7 Panels per MPPT)
- Based off Seraphim, Raystech, JINKO, JA Solar & GSun Solar Panel Specifications
- SUNSYNK 5kW 100Ah LiFePo4 Lithium Ion Battery
- Model SUN-BATT-5.32
- Display: SOC Status & LED Indicator
- Scalability: Max 8 Batteries in Parallel
- Nominal Voltage: 51.2V
- Nominal Capacity: 104Ah
- Battery Energy: 5320Wh
- Charge Voltage: 55.68-56.16Vdc
- Discharge Voltage: 45.6-56.15Vdc
- Nominal Charge & Discharge Current: 50A
- Maximum Charge & Discharge Current: 100A
- Nominal Charge & Discharge Power: 2500W
- Maximum Charge & Discharge Power: 5000W
- Short Circuit Current: 350A
- IP20
- IP Rating: ≤2000m
- Storage Temperature: ≤25°C (12 months); ≤35°C (6 months); ≤45°C (3 months)
- Cycle Life: 6000 Cycles @ 80% DOD/25°C/0.5C, 60% EOL
- Communication: CAN/RS485/RS232
- Installation Type: Floor Stand or Wall Mounted.
- Weight: 46.5Kg
- Dimensions (W x D x H): 450 x 520 x 185 mm
- 5 Year Limited Product Warranty
- Does Not Include Power Cables & Communication Cables (Sold Separately)
